- Place of Origin: Guangdong, China (Mainland)
- Brand Name: SOWZE
- Model Number: SW-AH1430NA-IR
>1/2.8" 2.1Megapixel Color CMOS
>Resolution : 19200(H)×1080(V) 2.1Mega Pixels
>Min. illumination : 0Lux/F1.2(IR ON)
>UP to 30 meters IR Distance
>IR cut function ,Day & Night surveillance
>Non coding compression ,High efficiency, without delay real-time transmission
>Up to 500 meters lossless transmission with 75-3 coax
>Compatible with normal 1080P
>Support 2D noise reduction, Lightning protection , anti-fog function
>Metal housing ,Inner line bracket ,multiple angle adjustable
>Waterproof Level : IP66
Model | SW-AH2030NA-IR |
Camera | |
Image Sensor | 1/2.8" 2.1Megapixel pixel Color CMOS |
Effective Pixels | 1920(H)×1080(V) 2.1M Pixels |
Electronic Shutter | PAL: 1/50 ~1/100,000s NTSC:1/60~1/100,000s |
System | PAL/NTSC |
Synchronization | Internal |
Min. Illumination | Color:1.0Lux(F1.2,50IRE,AGC ON), 0Lux with IR |
Video Output | 1.0Vp-p composite output, 75Ω |
Camera Features | |
Max. IR LED Distance | 15~30m, 35pcs Ф5/850nm IR LED |
Day/Night | ICR switch |
S/N Ratio | ≥60dB(AGC Off) |
White Balance | Auto |
Day & Night | ICR switch |
Privacy Mask | Support |
WDR | WDR |
Frame accumulation | 0-30X |
2D-DNR | Off / Low / Middle / High |
Image Freeze | Support |
BLC/HLC | Support |
Anti-fog | 0-2 grade |
Lens | |
Focal length | 3.6/6mm fixed M12 lens |
General | |
Power Supply | DC12V±10% |
Dimensions(W×D×H) | 180mm x72mm x 66mm |
Power Consumption | 0.72W/2.64W(IR ON) |
Working Environment | -20°C~ 60°C |
Transmission Distance | Over 500m via 75-3 coaxial cable |
Humidity | Relative humidity below 90% |
Language | Chinese / English / German / French / Italian / Spanish / Portuguese / Russian / Dutch / Turkish / Poland |
Weight(kg) | 0.52Kg |
